COMMERCIAL LINE
MIXERS
THE LINES OF PROFESSIONAL
MIXERS
DOUGH CAPACITY 60 to 80 Kg
CLASSIC LINE
PROFESSIONAL MIXER, VERSION WITH 2 MOTORS, DOUBLE SPEED WITH DOUBLE AUTOMATIC TIMER, PLUS REVERSE BOWL ROTATION.
• Manual panel control, easy to use
• 2 motors / 3-phase / 220V
• Bowl speed 14 rpm, Spiral arm two speed 105/210 rpm.
• 2 independent motors for spiral and bowl.
• Reverse bowl rotation.
• Control panel at the top of the machine.
• High resistance stainless steel bowl. Thick and wide breaking bar and reinforced spiral.
• Reinforced belt transmission, ideal for hydration above 55%.
• Mixing capacity from 60 to 80 kg
Add-on accessories:
• LED lights inside the bowl.
• Plexiglass bowl protection.
• Customized colors.
TECHNICAL SPECIFICATION
SUN60 CL
2 motors / 3-phase / 220V
Dough capacity
60 Kg/132 lb
Flour capacity
36 Kg/79 lb
Bowl
volume
qt 86
Amps
16
Watt
3500
Speed
2
Rpm
105/210
Outlet
3ph/220V
Dimensions
A B C
23" 39" 43"
Weight
lb
551
SUN80 CL
2 motors / 3-phase / 220V
Dough capacity
80 Kg/176 lb
Flour capacity
50 Kg/110 lb
Bowl
volume
qt 138
Amps
20
Watt
5500
Speed
2
Rpm
105/210
Outlet
3ph/220V
Dimensions
A B C
29" 47" 55"
Weight
lb
838
DOUGH CAPACITY 30 to 45 Kg
TOP LINE
Simple, robust and reliable machine designed to ensure optimal performance.
• Manual panel control, easy to use.
• 1 Motor / Single-phase / 220V
• Variable speed: 70 to 210 rpm
• Control panel at the top of the machine.
• High resistance stainless steel bowl, Thick and wide breaking bar and reinforced spiral.
• Mixing capacity from 30 to 45 kg
ADD-ON ACCESSORIES:
• LED Lights inside the bowl.
• Customized colors.
• 300 rpm.
TECHNICAL SPECIFICATION
SUN30 TL
1 motor / Single-phase / 220V
Dough capacity
30 Kg/66 lb
Flour capacity
18 Kg/40 lb
Bowl
volume
qt 48
Amps
10
Watt
2200
Rpm
70/210
Speed
Variable
speed
Outlet
1ph/220V
Dimensions
A B C
19" 31" 38"
Weight
lb
286
SUN40 TL
1 motor / Single-phase / 220V
Dough capacity
38 Kg/84 lb
Flour capacity
22 Kg/49 lb
Bowl
volume
qt 58
Amps
10
Watt
2200
Rpm
70/210
Speed
Variable
speed
Outlet
1ph/220V
Dimensions
A B C
21" 33" 38"
Weight
lb
309
SUN50 TL
1 motor / Single-phase / 220V
Dough capacity
45 Kg/99 lb
Flour capacity
26 Kg/57 lb
Bowl
volume
qt 71
Amps
12
Watt
2200
Rpm
70/210
Speed
Variable
speed
Outlet
1ph/220V
Dimensions
A B C
21" 37" 43"
Weight
lb
485
DOUGH CAPACITY 30 kg to 200 kg
QUEEN LINE
Professional mixer, version with 2 motors, variable speeds from 50 to 300 rpm, plus reverse bowl rotation. Touch screen control panel, temperature laser sensor, and LED light into the bowl.
• INVERTER - This technology allows the spiral speed to adapt to any hydration.
• 2 motors / Single-phase / 220V.
Size from 30 to 50.
• 2 motors / 3-phase / 220V.
Size from 60 to 200.
• Bowl speed 14 rpm, Spiral arm variable speeds from 50 to 300 rpm.
• 2 independent motors for spiral and bowl.
• Reverse bowl rotation.
• Control panel at the top of the machine.
• High resistance stainless steel bowl. Thick and wide breaking bar and reinforced spiral.
• Reinforced belt transmission, ideal for hydration above 55%.
ADD-ON ACCESSORIES:
• Plexiglas bowl protection.
• Customized colors.
TECHNICAL SPECIFICATION
QUEEN 30-1
2 motors / Single-phase / 220V
Dough capacity
30 Kg/66 lb
Flour capacity
18 Kg/40 lb
Bowl
volume
qt 48
Amps
10
Watt
2570
Rpm
70/300
Speed
Variable
speed
Outlet
1ph/220V
Dimensions
A B C
19" 31" 38"
Weight
lb
286
QUEEN 40-1
2 motors / Single-phase / 220V
Dough capacity
40 Kg/88 lb
Flour capacity
22 Kg/49 lb
Bowl
volume
qt 58
Amps
10
Watt
2570
Rpm
70/300
Speed
Variable
speed
Outlet
1ph/220V
Dimensions
A B C
21" 33" 38"
Weight
lb
309
QUEEN 50-1
2 motors / Single-phase / 220V
Dough capacity
50 Kg/110 lb
Flour capacity
26 Kg/57 lb
Bowl
volume
qt 71
Amps
12
Watt
2570
Rpm
70/300
Speed
Variable
speed
Outlet
1ph/220V
Dimensions
A B C
21" 37" 43"
Weight
lb
485
QUEEN 60-2
2 motors / 3-phase / 220V
Dough capacity
60 Kg/132 lb
Flour capacity
36 Kg/79 lb
Bowl
volume
qt 86
Amps
15
Watt
3500
Rpm
70/300
Speed
Variable
speed
Outlet
3ph/220V
Dimensions
A B C
23" 39" 43"
Weight
lb
551
QUEEN 80-2
2 motors / 3-phase / 220V
Dough capacity
80 Kg/176 lb
Flour capacity
50 Kg/110 lb
Bowl
volume
qt 138
Amps
20
Watt
5500
Rpm
70/300
Speed
Variable
speed
Outlet
3ph/220V
Dimensions
A B C
29" 47" 55"
Weight
lb
838
QUEEN 120-2
2 motors / 3-phase / 220V
Dough capacity
120 Kg/264 lb
Flour capacity
80 Kg/176 lb
Bowl
volume
qt 201
Amps
20
Watt
5500
Rpm
70/300
Speed
Variable
speed
Outlet
3ph/220V
Dimensions
A B C
31" 49" 55"
Weight
lb
882
QUEEN 160-2
2 motors / 3-phase / 220V
Dough capacity
160 Kg/353 lb
Flour capacity
100 Kg/220 lb
Bowl
volume
qt 282
Watt
9000
Speed
Variable
speed
Amps
35
Rpm
70/300
Outlet
3ph/220V
Dimensions
A B C
34" 56" 62"
Weight
lb
1445
QUEEN 200-2
2 motors / 3-phase / 220V
Dough capacity
200 Kg/441 lb
Flour capacity
125 Kg/275 lb
Bowl
volume
qt 323
Watt
9000
Speed
Variable
speed
Amps
35
Rpm
70/300
Outlet
3ph/220V
Dimensions
A B C
37" 57" 62"
Weight
lb
1499
EXCLUSIVE FEATURES
TOUCH SCREEN CONTROL PANEL
All the controls are enclosed in a touch screen panel, where you can store up to 12 recipes. Any operator will be able to use the saved recipes and create the same dough day after day, regardless of his skills. This fantastic device is provided by Mitsubishi.
TEMPERATURE LASER SENSOR
Detects the instant dough temperature, keeping it always under control, and avoid overheating the dough. In the Queen line, the mixer will stop automatically when it reaches the temperature you pre-set.
.jpg)
LED LIGHT BOWL
Illuminates the dough and facilitates viewing inside the bowl.
The LED light does not heat the dough.
DOUBLE AUTOMATIC TIMER
Works independently for the respective speeds, and also as an automatic switch from the first to the second speed, based on the pre-set timing.
REVERSE BOWL ROTATION
It only works up to 100 rpm, it allows you to mix without compacting the dough, perfect for some particular recipes with pre-ferments, as the biga.
